AC/DC Power Meter

AC/DC Power Meter

  • Can measure both AC signals and DC signals.The minimum current resolution reaches 0.01mA, and the minimum power resolution is 0.1mW, enabling standby power consumption measurement
  • Features sound and light alarms for over-limit voltage, current, and power, making it easy to quickly identify non-conforming products or abnormal conditions on-site
  • Supports Wh (watt-hour) and Ah (ampere-hour) integration
01
Supports voltage and current transformation ratio settings, easily expanding measurement range
02
Basic measurement accuracy of 0.2%
03
Fastest refresh rate of 0.1 seconds, enabling quicker signal capture.
04
Wide frequency measurement from DC to 1kHz/ 5kHz, stronger load adaptability

Equipment Introduction

1、Equipment description

The IDI310XL (+) -E/IDI310XLE-E series AC/DC power meters launched by Yidi Electronics are based on STM32F407VET6 and A3P125-VQG100 chips, integrating dual-channel (voltage, current) synchronized conversion, oversampling, RMS calculation, dynamic zero, zero-cross detection technology, widely used for measuring voltage, current, power, power factor, frequency, electrical energy, time, and other parameters of various electrical appliances, versatile with high measurement accuracy, fast speed, powerful functions, rich interfaces, strong anti-interference ability, fine workmanship, and reliable performance.

2、Functional Features

• Basic measurement accuracy of 0.2%；

• Input signal bandwidth DC, 15Hz-1KHz/5KHz；

• Suitable for both AC and DC measurement, can measure both AC signals and DC signals；

• Current resolution reaches 0.01mA, power resolution reaches 0.1mW, enabling measurement of standby power below 1W；

• Supports Wh and Ah integration to meet different customer testing needs；

• Voltage and current ratio setting functions, easily expanding measurement range；

• Over-limit sound and light alarms for voltage, current, and power, meeting on-site quick identification of abnormal products；

• RS-232 (standard) or RS-485 (optional) serial communication ports, USB interface (optional), easily achieving test automation and data transmission；

• Small and lightweight, exquisite appearance, reliable and stable operation；

3、Application scenarios


4、Technical Parameters

Model

IDI3102L(+)-E

IDI3103L(+)-E

IDI3102LE-E

IDI3103LE-E

Input Voltage/Frequency

Power supply: Configure according to the power grid of the country where this product is used.

Environmental temperature/humidity

20±10℃/〈75%

Whole machine no load

≤15W

Measurement function

Voltage U, Current I, Active Power P, Reactive Power Q, Apparent Power S, Power Factor λ, Phase Angle Φ, Voltage Frequency f, Voltage Peak Vpk, Current Peak Apk, Energy Wh, Current Integration Ah, Energy Timing Time

Voltage U, Voltage Frequency f, Current I, Active Power P, Reactive Power Q, Apparent Power S, Power Factor λ, Phase Angle Φ, Electric Quantity Ah, Energy Wh, Energy Timing Time, Average Power P

Basic measurement accuracy

Level 0.2

Range

600V20A

600V40A

600V20A

600V40A

Frequency measurement range

15Hz to 5kHz

15Hz to 1kHz

Measurement mode

RMS, DC, MEAN

RMS, AC, DC

Dimensions (mm)

281D*213W*99H

Configuration

LED display, 5 test groups, communication interface

LED display, 10 test groups, communication interface
